Satelitski GPS lokator model TK909 za kućne ljubimce,ovce,krave.

Radi na poziv, sms poruke ili preko aplikacije za nadzor uživo sa istorijom kretanja,određivanjem zone kretanja itd....

Tačnost lokacije je od 5 do 10 metara.

Baterija litijumska snage 1.000 mAh.

Memorisana istorija kretanja ostaju na aplikaciji 6 mjeseci.

Lokator koristi aplikaciju TKSTAR GPS ili WINNES GPS

Dužina kajša 65 cm.

Na profilu imam veliki izbor raznih pravih satelitskih lokatora.

Sve što prodajem na profilu je testirano ispravno i radi bez greške.

DOSTAVA PAKETA preko SkyTec Expres = 9 km.

Sadržaj paketa možete pregledati prije plaćanja.

Kupac plaća poštarinu jer nije uračunata u cijenu artikla.

Navedena cijena na artiklu je prodajna.

==================================================

The main function:

Real-time free tracking, GSM/GPS dual-mode positioning, positioning accuracy can reach within 5 meters;

1000 mAh super-capacity battery, which can stand for 240 hours with a single charge;

Small size, equipped with high-quality nylon pet collar;

Electronic fence, speeding, low battery alarm, voice monitoring.

Free tracking platform, computer, mobile client, IOS/Android APP, WeChat.

The user can download the mobile client directly or log in to the platform and enter the ID number on the back of the device as the user name. The initial password is: 123456.

Introduction

This product is based on the GSM/GPRS network and GPS satellite positioning system. It locates or monitors remote targets through short messages or mutual contacts. It is a technically accurate GPS and AGPS dual positioning.

LED indicator status                                   Description

Green light-steady on,                          the device is shut down or malfunctions

Green light-always on,                            not connected to GPRS network

Green light-flashing                                  GPRS network is normal

Red light-off,                                             fully charged

Red light-always on,                                         charging

Blue light-no light,                                 the device is off or malfunctions

Blue light-always on,                                     no GPS signal

Blue light-flashing                                      GPS signal is normal

2. Placement of the SIM card

Note: The card must be installed and then turned on again. If the card is installed after turning on the machine, it must be turned off and then turned on again during use.

Open the soft rubber plug, insert the GSM mobile phone card, pay attention to the direction of the card, and follow the plug icon.

3. Device startup

Take the device outdoors and press and hold the power button until the indicator light turns on.

When using device for the first time, please initialize to the default setting state. (Please refer to the instruction list in the manual)

After 10 to 40 seconds, the device will search for GSM and GPS signals and start to work normally. Under normal conditions, the indicator light of the device will keep flashing every 3 seconds.

After the device receives GPS signals normally, you can set any one of the instructions in the manual.

undefined

1. Google link: Google location map, you can use Google map or Google map to open it on your mobile phone.

2. V: A/V: GPS signal indication, A means GPS has signal, V means GPS has no signal.

3. 2014-07-29 06:41:43 Positioning time, default London time, Beijing time texting setting: timezone123456 8

4. S: 007km/h: speed, the speed at which the device moves

5. Bat: 80% battery power, the range is 5%-100%, when it reaches 40%, a low battery alarm will be issued.

6. 4109112546: Device IMEI number, use this number to log in to the website platform or APP.

3.2 Positioning use

1. Dial the phone in the device, and you will receive a positioning text message.

2. Send G123456# to the device, and you can also receive positioning text messages.

Note: If there is a master control number, all positioning messages will be sent to the master control number. If the master control number is not set, then the positioning information will be sent to the dialed number; G123456# Regardless of whether the master control number is set, the positioning information Will be sent back to the number that sent the text message.

3.3 Instruction list

Note: 1. The "+" sign in all commands does not need to be entered when writing a short message. "space" means the space symbol on the mobile phone.

2. SOS alarm information is only sent to the SOS number, and all other alarm information is sent to the main control number.

3. In the monitoring mode and positioning mode, the SMS positioning is normal, only the state of the phone in the device is changed.

4. Time sleep mode use time can reach about 8 days, vibration sleep use time is about 16 hours-8 days, turn off sleep mode use time is about 16 hours; after the device enters sleep, GPS and GPRS are all turned off and need to wake up. Start to work, please set the sleep mode according to their respective purposes, the factory default time sleep

4. Use online platforms

4.1 Turn on GPRS

Before using GPRS, send SMS to open GRPS

Send: GPRS123456 Reply: gps ok

4.2 Use mobile APP to locate

1. Android phone: Open www.tkstargps.net, download the Android version of the app, or search for tkstar in the google play store, and install it on the phone.

2. Apple mobile phone: search the tkstar gps application in the Apple App Store and install it on the mobile phone.

3. Select "IMEI Number Login"

Platform address: www.tkstargps.net

IMEI number: the IMEI number affixed to the back cover of the device

Password: The factory default is 123456 (you can log in to the platform to change the password)

4.3 Use platform positioning

1. Open the website: www.tkstargps.net

2. Choose :"License Plate Number/IMEI Number"

License plate number/IMEI number: the IMEI number affixed to the back cover of the device

Password: The factory default is 123456 (you can log in to the platform to change the password)

4.4 Use WeChat to locate

1. Add the public account "TKSTAR GPS".

2. After adding, bind the device according to the instructions on WeChat to query the location.

5. Matters needing attention

1. Confirm that the phone card has the functions of calling, SMS, and GPRS Internet access.

2. Confirm that there is enough balance.

3. Confirm that caller ID is enabled and call forwarding is turned off.

4. For the first use, please charge it for more than 3 hours.

5. Insert the GSM mobile phone card correctly.

6. Do not disassemble the equipment.

7. Please use the USB cable and charger configured by the manufacturer.

8. Common troubleshooting methods

Product Features:

Real-time tracking

Auto-tracking

Blind area tracking

GPS+GSM tracking

History-trace checking

SOS Alarm

Geo-fence

Movement alert

Overspeed alert

Low battery alert

Shaking sensor alert

Sleeping Working mode

 Note: SMS tracking works in GREEN-Solid mode and GREEN-Flashing mode,  online tracking only works in

GREEN-Flashing mode, turn on GREEN-Flashing mode by sending command “gprs123456” and set APN for the tracker.

Package included: (No retail box)

1pc* GPS tracker TK909

1pc* Charging cable

1pc* collar for pet  (Length*Width: 60cm*2.5cm about)

1pc* User manual
