3Com SuperStack II Dual Speed Hub 500 24-Port

GENERAL

• Subtype
  Fast Ethernet
• Ports
  24 x 10/100
• MAC Address Table Size
  4K entries
• Status Indicators
  Port status, collision status, power, link/activity
• Manufacturer
  3Com Direct

NETWORKING

• Cabling Type
  Ethernet 100Base-TX, Ethernet 10Base-T
• MAC Address Table Size
  4K entries
• Subcategory
  network hubs and switches
• Subtype
  Fast Ethernet
• Form Factor
  desktop
• Type
  hub
• Stackable
  stackable
• Connectivity Technology
  wired
• Features
  MDI/MDI-X switch, auto-sensing per device, full duplex capability, manageable, stackable
• Compliant Standards
  IEEE 802.1D, IEEE 802.3, IEEE 802.3u
• Ports Qty
  24
• Manageable
  Yes
• Switching Protocol
  Ethernet
• Remote Management Protocol
  RMON, RMON 2, SNMP
• Communication Mode
  full-duplex, half-duplex

POWER DEVICE

• Nominal Voltage
  AC 120/230 V
• Frequency Required
  50/60 Hz
• Power Consumption Operational
  49 Watt
• Type
  internal power supply

INTERFACE PROVIDED

• Interface
  Ethernet 10Base-T/100Base-TX, console
• Qty
  1, 2, 24
• Connector Type
  9 pin D-Sub (DB-9), RJ-45
• Comments
  management

MISCELLANEOUS

• Rack Mounting Kit
  included
• Mounting Kit
  included
• Height (Rack Units)
  1 m

CHASSIS

• Installed Devices / Modules Qty
  0
• Supported Devices / Modules Qty
  2

ENVIRONMENTAL PARAMETERS

• Min Operating Temperature
  32 °F
• Max Operating Temperature
  122 °F
• Humidity Range Operating
  0 - 95%

HEADER

• Brand
  3Com
• Product Line
  3Com SuperStack II
• Model
  Dual Speed Hub 500
• Packaged Quantity
  1
• Country Kits
  United States
• Compatibility
  PC

DIMENSIONS & WEIGHT

• Width
  17.3 in
• Depth
  12.2 in
• Height
  1.7 in
• Weight
  5.95 lbs

SOFTWARE

• Type
  3Com Network Supervisor (Trial), Transcend Network Supervisor

EXPANSION BAYS

• Type
  none

PORTS

• Type
  10/100
• Qty
  24

EXPANSION SLOTS

• Type
  expansion slot
• Total Qty
  2
• Free Qty
  2

SLOT REQUIRED

• Type
  none

SERVICE & SUPPORT

• Type
  limited lifetime warranty

SERVICE & SUPPORT DETAILS

• Service Included
  replacement
• Full Contract Period
  5 years, lifetime
• Type
  limited warranty

GENERAL

• Manufacturer
  3Com Direct
