Mini PC Cappuccino TX2

Processor

 Intel Pentium III / Celeron Processor in FCPGA package
 Supports processors 370-pin socket
 Upgradable to Pentium III 1Ghz and higher
 System bus frequency at 100MHz and 133MHz

Memory

 One 144-pin DIMM slot for PC100/133MHz SDRAM
 Upgradable to 256MB

Video  Intel 82815, Video Memory 4MB (shared Memory).
 Supports up to 1280 by 1024-pixel at 24bits per pixel
 15 pin mini-D-sub VGA connector
 One S-Video port
 One AV Video port

Speakers & Audio

 Built-in 16-bit stereo (Sound Blaster / Adlib compatible)
 Built-in Speaker

Communications

 Built-in IrDA
 Built-in 10/100Base-T Ethernet(RJ45)
 Built-in 56K V.90 Modem
 Modem connector(RJ11)

Peripheral Connection

 Four USB ports (12Mbps each)
 Two FireWire (1394) ports (400 Mbps each)
 One 9 pin Serial port (RS-232)
 One 25 pin Parallel port (EPP/ECP)

Keyboard / Mouse  Supports any standard PS2/USB mouse
 One 6 pin PS/2 Mouse port
 One 6 pin PS/2 Keyboard port

Electrical Requirements   Line voltage 110V (90V to 130V AC) or 230V AC (180V to 260V AC)
 Frequency: 47 to 63Hz, single phase
 Power in: DC 18V / 3A
 Max. power 54Watt

Environmental Requirements  Operation Temperature: 10C to +35C
 Storage Temperature: -10C to +55C
 Relative humidity 5% to 95% non-condensing
 Altitude: 0 to 10,000 feet

Operating System   Windows 98 Second Edition
 Windows 2000
 Windows NT
 Windows ME

Storage  One 2.5" Hard Disk and 9.5mm height. (Support Ultra DMA 33/66)
 One ATAPI-IDE interface high speed CD-ROM
 DVD-ROM, CD-RW Optional external hot swap Pa
 Optional external hot swap Parallel Port FDD

Weight & Size  System approximately 1.9lbs
 System Dimensions: 156mm x 146mm x 56mm
